High-Performance Deburring and Finishing Systems

Costa Levigatrici: MD Series

product

Modular Power for Industrial Surface Finishing

Magal Engineering introduces the Costa MD Series – the best Finishing system built for deburring, polishing, and edge rounding  applications for light to moderate steel metal carpentry..

Designed for high productivity and Repeatability, the Costa MD machines feature a modular working unit architecture, allowing up to 5 top or 4 bottom units to be configured per customer requirements. Whether for heavy slag removal or fine polishing, each unit is engineered to deliver high-quality surface finishes, even on warped or thin parts.

The machine combines the robustness of finishing machinery with advanced features like floating heads, magnetic hold tables, and abrasive belts up to 3250 mm, significantly reducing labour and operating cost.,

It is equipped with a samsung PLC control which has been designed after decades of R&D to accommodate material irregularities to ensure consistent repeatable results with close to 100% uptime.

Magal Engineering introduces the Costa MD Series – the best Finishing system built for deburring, polishing, and edge rounding  applications for light to moderate steel metal carpentry..

Designed for high productivity and Repeatability, the Costa MD machines feature a modular working unit architecture, allowing up to 5 top or 4 bottom units to be configured per customer requirements. Whether for heavy slag removal or fine polishing, each unit is engineered to deliver high-quality surface finishes, even on warped or thin parts.

The machine combines the robustness of finishing machinery with advanced features like floating heads, magnetic hold tables, and abrasive belts up to 3250 mm, significantly reducing labour and operating cost.,

It is equipped with a samsung PLC control which has been designed after decades of R&D to accommodate material irregularities to ensure consistent repeatable results with close to 100% uptime.

Key Features

  • Available in widths: 650 mm to 1650 mm
  • Up to 5 internal working units, 2 external (top/bottom)
  • Long abrasive belts: 2620–3250 mm for longevity and consistent finish
  • Modular working center with interchangeable units
  • ±0.025 mm surface tolerance with high-rigidity frame and T1 steel feed table

Working Unit Options

  • Cylinders (Ø 200, 250, 330 mm – hard/soft rubber)
  • Brush Units (Rotary, Orbital, Vertical, Longitudinal)
  • Deslagging Heads for heavy-duty removal
  • SB Series Brushes for Scotch-Brite™ finish on delicate metals

Control Panel Display Includes

  • Electronic grit-set and pneumatic standby
  • Belt tracking with misalignment protection
  • Safety over-thickness roller stop system

Optional Accessories

  • Vacuum feed table for small/oily parts
  • Magnetic hold system
  • Feed belt cleaning blowers (JFB)
  • Liquid-cooled inserts for ultra-precision work

Industries & Applications

  • General fabrication(precision sheet metal)
  • Fine Blanked parts(automotive)
  • Aluminium Structural components(aviation,aerospace)
  • Electrical electronics(copper and aluminium Busbars finishing)
  • Medical Equipments
  • Food processing industry(SS 304L-high chromium steel finishing)
  • Pharmaceutical assembly lines
